CABINET SHELF 4 POINT RACK MOUNTING

PART DESCRIPTION

OVERALL ADJUSTABLE MOUNT DEPTH: 6" TO 33.475" *
OVERALL ADJUSTABLE MOUNT DEPTH: 6" TO 26.625" *
OVERALL ADJUSTABLE MOUNT DEPTH: 6" TO 23.625" *

• SHELF FITS IN CABINETS AND FOUR POST RACKS

* SHELF LOAD CAPACITY: 200LBS

•Accessories Catalogue Page 1-8A (PDF)

CABINET SHELF 4 POINT RACK MOUNTING

PART DESCRIPTION

OVERALL ADJUSTABLE MOUNT DEPTH: 23.75" TO 45.50" *

* SHELF LOAD CAPACITY: 400LBS

•Accessories Catalogue Page 1-8B (PDF)

RETRACTABLE CABINET SHELF 4 POINT RACK MOUNTING

PART DESCRIPTION

19" EIA RACK MOUNT RETRACTABLE SHELF - 1U*

• SHELF MOUNTS ON 4 MOUNTING ANGLES
• SHELF IS 17"WIDE x 26" DEEP

* SHELF LOAD CAPACITY: 100LBS

• Accessories Catalogue Page 1-10AAA (PDF)

RACK SHELF FIXED

PART DESCRIPTION

19" EIA RACK - SINGLE-SIDED FIXED SHELF   9" DEEP*
19" EIA RACK - SINGLE-SIDED FIXED SHELF 12" DEEP*
19" EIA RACK - SINGLE-SIDED FIXED SHELF 15" DEEP*
19" EIA RACK - SINGLE-SIDED FIXED SHELF 21" DEEP*

23" EIA RACK - SINGLE-SIDED FIXED SHELF 15" DEEP*
23" EIA RACK - SINGLE-SIDED FIXED SHELF 21" DEEP*

24" EIA RACK - SINGLE-SIDED FIXED SHELF 15"DEEP*
24" EIA RACK - SINGLE-SIDED FIXED SHELF 21"DEEP*

* SHELF LOAD CAPACITY: 100LBS

• Accessories Catalogue Page 2-2 (PDF)

RACK SHELF RETRACTABLE KEYBOARD

PART DESCRIPTION

19" EIA RACK - RETRACTABLE KEYBOARD SHELF c/w MOUSE TRAY*
23" EIA RACK - RETRACTABLE KEYBOARD SHELF c/w MOUSE TRAY*
24" EIA RACK - RETRACTABLE KEYBOARD SHELF c/w MOUSE TRAY*

* SHELF LOAD CAPACITY: 100LBS

• Accessories Catalogue Page 2-5 (PDF)

RACK SHELF RETRACTABLE - PIVOTING KEYBOARD

PART DESCRIPTION

19" EIA RACK - RETRACTABLE-PIVOTING KBD SHELF c/w MOUSE TRAY
23" EIA RACK - RETRACTABLE-PIVOTING KBD SHELF c/w MOUSE TRAY
24" EIA RACK - RETRACTABLE-PIVOTING KBD SHELF c/w MOUSE TRAY

• Accessories Catalogue Page 2-5A (PDF)

RETRACTABLE LCD MONITOR KEYBOARD SHELF

PART DESCRIPTION

19" MOUNT - EQUIPPED W/KBD, BLACK TOUCH-PAD, AND 17" LCD DISPLAY

• Accessories Catalogue Page 2-5B (PDF)

FOLDING KEYBOARD TRAY

PART DESCRIPTION

19" MOUNTING - FLIPS UP AND HAS RETRACTABLE MOUSE PAD SURFACE
23" MOUNTING - FLIPS UP AND HAS RETRACTABLE MOUSE PAD SURFACE
24" MOUNTING - FLIPS UP AND HAS RETRACTABLE MOUSE PAD SURFACE

• Accessories Catalogue Page 3-7 (PDF)

RACK SHELF FIXED DOUBLE SIDED

PART DESCRIPTION

19" EIA RACK - DOUBLE-SIDED FIXED SHELF 20" DEEP*
19" EIA RACK - DOUBLE-SIDED FIXED SHELF 28" DEEP*

23" EIA RACK - DOUBLE-SIDED FIXED SHELF 15" DEEP*
24" EIA RACK - DOUBLE-SIDED FIXED SHELF 20" DEEP*

* SHELF LOAD CAPACITY: 200LBS

• Accessories Catalogue Page 2-3 (PDF)

RACK SHELF RETRACTABLE

PART DESCRIPTION

19" EIA RACK - RETRACTABLE SHELF 20" DEEP*
23" EIA RACK - RETRACTABLE SHELF 20" DEEP*
24" EIA RACK - RETRACTABLE SHELF 20" DEEP*

* SHELF LOAD CAPACITY: 100LBS

• Accessories Catalogue Page 2-4 (PDF)

FIXED SHELVES FOR CABINETS

PART DESCRIPTION

STD. FIXED SHELF FOR ALL 30.0"W CABINETS
STD. FIXED SHELF FOR ALL 30.0"W X 36.0"D CABINETS*

STD .FIXED SHELF FOR ALL 24.0"W x 30.0"D CABINETS
STD .FIXED SHELF FOR ALL 24.0"W x 36.0"D CABINETS*

note: CFS SERIES SHELVES REQUIRE Z-RAILS FOR MOUNTING

*ALSO FITS 42.0"D CABINETS

•Accessories Catalogue Page 1-8 (PDF)

WIDE SLIDING SHELF FOR CABINETS

PART DESCRIPTION

RETRACTABLE SHELF FOR ALL 30"W x 30"D CABINETS (STANDARD)
RETRACTABLE SHELF FOR ALL 24"W x 30"D CABINETS (NARROW)

note: CRS SERIES SHELVES REQUIRE Z-RAILS FOR MOUNTING

• Accessories Catalogue Page 1-9 (PDF)

NARROW SLIDING SHELF FOR CABINETS

PART DESCRIPTION

NARROW RETRACTABLE SHELF FOR ALL 30"W x 30"D CABINETS

note: CRS SERIES REQUIRE Z-RAILS FOR MOUNTING

• Accessories Catalogue Page 1-10 (PDF)
