CPI eConnect® PDUs — Power Management Solutions








Power Bars [Horizontal and Vertical] — Catalogue Page 6.1.1





PART NUMBER

RFM-19-PBH-8
RFM-19-PBHT

RFM-19-PBH-20A
RFM-19-PBHT-20A

RFM-48-PBV-18

RFM-62-PBV-24

RFM-52-PBVT
RFM-76-PBVT

RFM-52-PBV-20A
RFM-62-PBV-20A-24
RFM-62-PBVT-20A-24

PART DESCRIPTION

19"EIA Horizontal, 15A Rated, c/w 8 Outlets (2 Front, 6 Rear)
19"EIA Horizontal, 15A Rated, c/w 6 Outlets Twistlock

19"EIA Horizontal, 20A Rated, c/w 6 Outlets
19"EIA Horizontal, 20A Rated, c/w 6 Outlets Twistlock

48"H Vertical, 15A Rated, c/w 18 Outlets
62"H Vertical, 15A Rated, c/w 24 Outlets

48"H Vertical, 15A Rated, c/w 8 Outlets, Twistlock
76"H Vertical, 15A Rated, c/w 12 Outlets, Twistlock

48"H Vertical, 20A Rated, c/w 8 Outlets
62"H Vertical, 20A Rated, c/w 24 Outlets
62"H Vertical, 20A Rated, c/w 24 Outlets, Twistlock

Notes:
- Horiz & Vertical Models - Std. Colour Is Black
- Horiz & Vertical Models - Std. Cord Length Is 15' (4.57M)
- Horiz Power Bars Also Available In 23" And 24" Mounting



PDU Bracket — Catalogue Page 6.2.6





PART DESCRIPTION

Enables mounting of 3rd party vertical PDU - 83" H Cabinet
Enables mounting of 3rd party vertical PDU - 90" H Cabinet


Grounding Bars [Vertical & Horizontal] — Catalogue Page 1.5.8









PART NUMBER

RFM-GB-90
RFM-GB-83
RFM-GB-72
RFM-GB-59

RFM-GBR-90
RFM-GBR-83
RFM-GBR-72
RFM-GBR-48

RFM-HGB-19


RFM-GB-90-ISOKIT
RFM-GB-83-ISOKIT
RFM-GB-72-ISOKIT

RFM-GB-59-ISOKIT
PART DESCRIPTION

Vert. mnt. copper bar 1"w x 3/16" thick — fits 90"h Cabinets
Vert. mnt. copper bar 1"w x 3/16" thick — fits 83"h Cabinets
Vert. mnt. copper bar 1"w x 3/16" thick — fits 72"h Cabinets
Vert. mnt. copper bar 1"w x 3/16" thick — fits 59"h Cabinets

Vert. mount copper bar 1"w x 3/16" thick — fits 48U Racks
Vert. mount copper bar 1"w x 3/16" thick — fits 44U Racks
Vert. mount copper bar 1"w x 3/16" thick — fits 38U Racks
Vert. mount copper bar 1"w x 3/16" thick — fits 24U Racks

Horiz. mount copper bar 1"w x 3/16" thick. — 19" EIA Mount

Low-Voltage Insulator, 1/4" Thread, 600VAC — Pkg of 4
Low-Voltage Insulator, 1/4" Thread, 600VAC — Pkg of 4
Low-Voltage Insulator, 1/4" Thread, 600VAC — Pkg of 3
Low-Voltage Insulator, 1/4" Thread, 600VAC — Pkg of 3

Grounding Kit — Catalogue Page 6.1.3





PART NUMBER

RFM-GRD-KIT

PART DESCRIPTION

Kit c/w 2 Assemblies, each assembly consists of:
• 2 x 10 Awg Wire
• 16” Cable Length (0.406 M) (Each Cable)
• 2 x 1/4” Crimped Lug Connectors (1 Eye Hole)
• 1 x m/f 250 Disconnect


Jumper Kit — Catalogue page 6.1.3





PART NUMBER

RFM-JK-60

PART DESCRIPTION

Kit assembly consists of:
• 6 Awg Wire
• 60” Cable Length (1.54 M)
• Crimped One End: 1/4” Lug Connector
   (45 Degree Angle, 2 Eye Holes)
